Description:
▲AHIGH SAFETY:The product is equipped with an oil alarm. If enough oil is not added before starting, the machine will automatically turn off to protect the machine. Thus the machine will not be easily damaged and has a longer service life.
▲LOW FUEL CONSUMPTION&LOW NOISE: The overhead valve is used, which effectively helps reduce carbon buildup and dramatically improves fuel savings. Air filter also improves air filtration performance and reduce wear. Both can help you save a lot of money on fuel costs,The product adopts a silencer, which has a good noise reduction effect. This engine works hard to create a quiet working environment for you.
▲APPLICABLE SCENARIOS:This product is widely used in can be applied to go-karts, compressors, trenchers, generators, high-pressure washers, cement mixers, etc, as long as the crankshaft matches.
▲STRONG POWER&LARGE CAPACITY: The gasoline engine boasts a robust 15HP/13HP horsepower, a displacement of 420cc/389cc and a rotating speed of 3600RPM, which provides you with strong power and ensures that your work can be completed quickly and easily,The engine has a large 1.7 gallon (6.5L) fuel tank for long hours of operation. You don't need to refuel as often, which is very convenient.
▲STABLE RUNNING&EFFICIENT COOLING SYSTEM: The engine is equipped with metal cam, forged crankshaft and cast iron cylinder liner, ensuring superior performance and a longer lifespan. Manually starting the engine/Electric start engine ,The built-in forced air cooling system and ventilated heat sink are designed to keep the motor cool and provide high reliability and durability.
Product Specification:
Color: Red
Starter System: Hand Start
Maximum Torque: 28N.m
Bore Stroke: 90*68mm/3.54*2.68inch
Displacement: 420cc
Horsepower: 15hp
Rated Power: 9600W
Maximum Power: 11000W
Product Specification:
Color: Black
Starter System: Hand Start
Maximum Torque: 28N.m
Bore Stroke: 90*68mm/3.54*2.68inch
Displacement: 420cc
Horsepower: 15hp
Rated Power: 9600W
Maximum Power: 11000W
Product Specification:
Color: Red
Starter System: Electric start
Maximum Torque: 28N.m
Bore Stroke: 90*68mm/3.54*2.68inch
Displacement: 420cc
Horsepower: 15hp
Rated Power: 9600W
Maximum Power: 11000W
Product Specification:
Color: Black
Starter System: Electric start
Maximum Torque: 28N.m
Bore Stroke: 90*68mm/3.54*2.68inch
Displacement: 420cc
Horsepower: 15hp
Rated Power: 9600W
Maximum Power: 11000W
Product Specification:
Color: Red
Starter System: Hand Start
Maximum Torque: 26.5N.m
Bore Stroke: 88*64mm/3.4*2.5inch
Displacement: 389cc
Horsepower: 13hp
Rated Power: 8600W
Maximum Power: 9600W
Product Specification:
Color: Black
Starter System: Hand Start
Maximum Torque: 26.5N.m
Bore Stroke: 88*64mm/3.4*2.5inch
Displacement: 389cc
Horsepower: 13hp
Rated Power: 8600W
Maximum Power: 9600W
Product Specification:
Color: Red
Starter System: Electric start
Maximum Torque: 26.5N.m
Bore Stroke: 88*64mm/3.4*2.5inch
Displacement: 389cc
Horsepower: 13hp
Rated Power: 8600W
Maximum Power: 9600W
Product Specification:
Color: Black
Starter System: Electric start
Maximum Torque: 26.5N.m
Bore Stroke: 88*64mm/3.4*2.5inch
Displacement: 389cc
Horsepower: 13hp
Rated Power: 8600W
Maximum Power: 9600W
Product Specification:
Type: Single Cylinder, 4-stroke
Material: Aluminium, Iron
Surface Treatment: Shot Blasting, Color Galvanizing, and Plastic Spraying
Power Source: Gasoline
Engine Cooling Type: Air Cooling
Crankshaft Diameter: 25mm/0.98inch
Crankshaft total length: 100.5 mm / 3.96 inches
Crankshaft effective length: 57 mm / 2.24 inches
Rotational Speed: 3600rpm
Lubrication Oil Capacity: 1.1L/0.29 Gallon
Fuel Tank Capacity: 6.5L/1.7 Gallons
Fuel Consumption Rate: ≤325g/ kw. h
Gross Weight: 31kg/68.34lbs
Net Weight: 28.5kg/62.83Ibs
Product Size: 48*38*45cm/18.89*14.96*17.71inch
Package Size: 52*42*49cm/20.47*16.53*19.29inch
Package Included：
1* Gasoline Engine
1* Multilingual Manual
All Accessories for Assembly
NOTE:
1.Professional installation is highly recommended
2.Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before you order.
