50' Belden 9745 22 AWG 3 Pair Instrumentation Cable PVC Jacket 300V Click Thumbnails to EnlargeDESCRIPTION
• Belden 9745 22 AWG 3 Pair Tinned Copper Instrumentation Cable PVC Jacket 300V
APPLICATION
• Low Voltage Analog Signals (4-20ma, 0-10v, ...)
• Low Voltage Control (24v, …)
• Line Level Audio; Computer Communication; Panel Wiring
CONDUCTOR
• Tinned Copper
INSULATION
• Polyvinyl Chloride (PVC)
OUTER JACKET
• Polyvinyl Chloride (PVC)
STANDARDS
• Environmental Suitability: Indoor
• Flammability / Reaction to Fire: UL 1685 FT4 Loading, FT4, IEC 60332-1-2
• CPR Compliance: CPR Euroclass: Eca
• NEC / UL Compliance: Article 800, CMG
• AWM Compliance: AWM 2576
• CEC / C(UL) Compliance: CMG
• European Directive Compliance: EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
• UK Regulation Compliance: UKCA Mark
• APAC Compliance: China RoHS II (GB/T 26572-2011)
PRODUCT SPECIFICATIONSSize AWG 22Number of Pairs 3Number of Strands 7Insulation Thickness (inch)0.011Jacket Thickness (inch)0.032Overall Diameter (inch)0.245Weight (lbs/1000ft)32
