Universal Fit Design: Designed to fit a variety of universal radiators with core widths from 22″ to 33″ and accommodate a single 16-inch electric cooling fan., Durable Aluminum Construction: Made from rugged laser-cut and press-bent .063″ 3003 H14 aluminum for strength and long service life in automotive cooling applications., Optimized Airflow: Pre-cut 15.5″ diameter opening focuses airflow through the electric fan and across the entire radiator core for better cooling performance., Bolt-On Installation: Attaches easily to radiator top and bottom channel lips with simple bolt-on or screw-on mounting (hardware sold separately), making installation quick., Customizable Setup: Electric fan, wiring kit, and cooling accessories not included; pairing with quality fans and controllers improves h Aluminum Fan Shroud For Speedway Motors Radiators, Single Fan, 22 Sku # 9175021-22 Mfr. Part # 9175021-22 Condition New Brand Speedway Motors Sold Each Details
- Available in six different radiator widths to match our universal radiators core width
- Built from .063-inch 3003 H14 sheet aluminum, laser cut, and press bent
- Features a centered 15.5" dia. pre-cut electric fan opening for 16-inch diameter fans
- Most weigh less than two pounds (31- and 33-inch approximately 2.5-pounds)
- Mounts via radiator’s upper and lower core channel edges
- Electric fan, wiring/relay kit, and rubber cooling flaps sold separately
When Space Is at A Premium, An Electric Cooling Fan Is a Must
Engine driven fans have been around for more than a century and provide a simple solution to pulling ambient air through the vehicle’s radiator to reduce cooling system temperatures. Often used with a radiator mounted The Toolbox: Does a Fan Shroud Make a Difference They work well in stock engine/chassis environments but can often become a source of frustration when performing engine swaps or upgrading to thicker radiators to combat elevated temperatures in performance engine builds. Enter the electric cooling fan.
The electric cooling fan, once a staple of engine swaps and race car builds has become the preferred OEM cooling fan of choice, and for The Toolbox: Electric Radiator Cooling Fan Guide. They do not take away from engine horsepower, provide a much more compact cooling fan solution, and can be controlled in several ways (manual switch, thermal switch, modulated fan controller, etc.). The only drawback to an electric cooling fan has been in how to mount them to your radiator. Through the core mounts and universal brackets are the norm, but neither product is a secure fan mount and can damage your radiator’s core fins or tubes. Our new electric fan shroud provides a quick and secure way to mount an The Toolbox: What to Consider When Choosing an Electric Radiator Cooling Fan while also providing an effective cooling solution by forcing air to be pulled through the whole radiator core and not just through the fan’s diameter area.
Designed To Fit Radiators with Lip-Style Upper and Lower Channels
We made our aluminum fan shroud to fit our universal Shop Single Pass Universal SBC/BBC Aluminum Radiators and Shop Double Pass Universal SBC/BBC Aluminum Radiators SBC/BBC radiators, but honestly this universal fan shroud will work with many Shop Crossflow Radiators using lip-style upper and lower radiator channels. Measure your radiator carefully and refer to the product drawings provided to confirm fitment on radiators other than those mentioned above.
Installation of our aluminum radiator shroud is easy with the shroud’s upper mount hooking to the radiator channel’s upper lip. At the bottom of the radiator shroud, we left final retention to the end user. You can attach your fan shroud’s bottom lip via rivets, tapping screws, or small bolt/locknut hardware. The pre-cut 15-1/2-inch fan opening is designed to work with most any Shop 16-inch Electric Cooling Fans and there is ample radiator shroud surface area to add rubber Radiator Shroud Rubber Cooling Flaps if desired for highway speed cooling passthrough needs.
Specs Hole Diameter 15.50" Overall Width 16.63" Overall Height 19.43" Depth 0.97" Material Thickness .063" Material Type Aluminum Installation Type Bolt-On / Screw-On Finish Bare Hardware Included No Sold in Quantity Each MFG. Part # 9175021-22 Reviews Great, Fit Jegs Radiator Rated by Buggymax on March 30, 2026
Summary: This has worked great for me on my Jegs radiator. Dimensions were true and fitment was good. Used a little puffy tape to seal the cracks and hasnt needed adjusted since installed. Made a ton of difference in cooling, fan runs so much less.
Yes, I recommend this product.
Best shroud Rated by Down ranger on March 25, 2026
Summary: Great fan shroud fits perfectly
Yes, I recommend this product.
OUTSTANDING PRODUCT Rated by WEN on February 27, 2026
Summary: I was concerned regarding how this would arrive and then install since it is aluminum and would damage VERY easy in shipping. It arrived On TIME and was packaged very well to prevent damage from handling. In addition, it was completely covered on the finished side with a protective "peel off" coating. The dimensions I had to work with were VERY critical and it was ESSENTIAL for this to be exactly as advertised in order to fit. Low and behold, it was PERFECTLY sized and once I drilled the mounting holes it fit perfectly in place with NO additional alterations or fabrication of ANY sort.
I really had to modify this shroud. It must only fit one bra Rated by PastorFreddiek on November 05, 2025
Summary: Although the quality is good, the fit was a killer. Took a few hours.
No, I would not recommend this product.
I would buy this again Rated by Rob on October 03, 2025
Summary: I used this shroud to mount a 16" e-fan in my LS swapped BMW 750Li. My car would not stay below 180 degrees without it and now I can idle through pits and paddocks at 165 consistently.
Yes, I recommend this product.
