GTDK AVR 5.5KW 6.0KW 6.5KW 6.8KW 7.5KW 8.0KW for China Gasoline Diesel Generator For Sale

Product Description:Premium 5.5KW to 7.5KW Generator Automatic Voltage Regulator(AVR) for Brush Alternator, especially for all China-Made Gasoline Generators Applied with 188F(389CC & 401CC Displacement) & 190F(420CC Displacement) Gas Engines. It can handle maximum surge power up to 8.5KW. It fits & works perfect on all China-made portable diesel brush generators with 186F engine as well.It is completely interchangeable with GTDK AVR up to 8.5KW power output.Alternator Rear Cover/Stand & Carbon Brush AssemblyNOT Includedand Sold Separately.

Seller\'s Statement:
Many other sellers just used our part number, and directly copied our product description as well; however, their product is totally different from ours.Many products look very similar externally, but their internal design is very different.An incompatible AVR will damage and burn your generator head/alternator. Most of their AVRsare rated only 5KW, tons of which can be dug out of through the search of key word 5KW AVR at the cost of around $25(wire colors may be different).They are too weak to be used unless the total load of your generator won\'t exceed 5KW!Their use on your generator probably causes serious damage to the alternator/generator head.Packing Contents: 1 X AVR-5575-GTDK.

Special Note:
1)A higher output AVR definitely works perfect on a generator of low power output while on the contrary, a low power output AVR CAN NOT be used for a generator of higher power output.
2)If our AVR is out of adjustment for your generator, please MANUALLY turn clockwise or counter-clockwise a small bronze screw in a blue rubber part to reach your desirable power output. Clockwise turning is for increasing and counter-clockwise turning for decreasing voltage output.If this does not help you out, please contact with us for tech support.

Part Number:
AVR-5575-GTDK.

Product Features:

1. Built-in Full-Wave Output Bridge Rectification.
2. Voltage Output Increase with Loading.
3. Stable Voltage Output with Negative Voltage response.
4. Over Voltage, Over Current and Short Circuit Protection.
5. Large Manual Adjustable Voltage Output Range of 160V ~ 260V for 240V output.


Technical Specifications:

1. Maximum Output: DC 90V 3.5A.
2. Excitation Voltage: 90V ~ 100V.
3. response Voltage: 14V ~ 24V with an Average of 18V.
4. Frequency: 50/60Hz.
5. AC Voltage Output: 120V/240V.
6. Auto Voltage Adjusting Accuracy: ≤ ±1%.
7. Maximum Temperature Rise: 130C or 266F.
8. Continuous Working Time: ≥ 20 Hours.
9. Installation-Center Distance: 140 ± 1mm (about 5.5 in).


Shipping:
We ship worldwide. Please contact us and confirm international shipping & handling fee for shipping out of USA before you place an order with us.Warranty:
We warrant our PRODUCTS against manufacturer defectsin materials, workmanship and finish under normal use and service for three (3) months from the original date of purchase. Please retain the dated invoice as evidence of the date of purchase. You will need it for any warranty service. Return:
Ifyou are not satisfied with our items and want to return to us, pleasecontact us for a Return Material Authorization (RMA)number within 30 days of receipt before you arrange for return. We DO NOTaccept any return without RMA number. Non-authorized returns will berefused and sent back to YOU at your cost. We do not take return after 30 days of receipt of our product. We offerfree replacement and exchange service for the goods after 30 days ofreceipt.

Customers are responsible for all return shipping charges incurred. Shipping and handling fee is NON-REFUNDABLE under any circumstances.

Payment:
We take credit card payment for domestic customers in USA only. Payment through Paypal is alsoacceptable.For international customers, we only take payment through Paypal.

Thank you for the interest in our products, welcome to coming and taking a look next time.
