Complete John Deere technical/service manual covering 325 and 345 Lawn & Garden Tractors, supplied on CD-ROM.
Manual Number: TM1574
Edition: 02FEB95
Manual Type: Technical Service Manual
Models Covered: John Deere 325 and 345 Lawn & Garden Tractors
Format: CD-ROM
Language: English
PDF Length: 468 pages
This manual covers troubleshooting, testing, adjustments and repair for the John Deere 325 and 345. It is organized by tractor system and includes specifications, component locations, schematics, theory of operation, troubleshooting charts, diagnostics, tests, adjustments and repair procedures.
Major Sections Include
- Safety
- Specifications and general information
- 325 engine
- 345 engine
- Electrical system
- Hydrostatic power train
- 325 steering
- 345 steering
- Brakes
- Hydraulics
- Attachments
- Miscellaneous service information
The manual separates the engine and steering information for the two models so the correct procedures are easy to locate.
Engine Coverage
John Deere 325
- FC540V gasoline engine
- Air cooled
- Single cylinder
- 535 cc / 32.6 cu. in.
- 17 HP
- Pressurized lubrication
- Full-flow oil filter
John Deere 345
- FD590V gasoline engine
- Liquid cooled
- V-twin
- 585 cc / 35.7 cu. in.
- 18 HP
- Pressurized lubrication
- Full-flow oil filter
Power Train & Electrical Coverage
The manual includes service information for:
- Hydrostatic transmission
- Twin Touch foot controls
- PTO drive and electric clutch
- Transmission belt
- Cruise control
- Charging system
- Starter
- Battery
- Ignition system
- Interlock switches
- Lights and gauges
The specifications identify the transmission as a hydrostatic piston-type unit with Twin Touch foot control and give factory forward and reverse travel speeds.
Steering, Brakes & Hydraulics
Coverage includes:
- Manual steering system on the 325
- Hydraulic power steering on the 345
- Internal wet-disc brakes
- Hydraulic lift system
- Lift control valve
- Hydraulic filter
- Cutting-unit lift system
Mower & Attachment Information
The manual also contains attachment-related service information, including mower systems. The specifications include information for 38-inch, 44-inch, 48-inch and 54-inch mower decks.
Additional general information includes fuel and lubricants, torque specifications and serial-number locations for the tractor, engines, carburetors, hydrostatic transmission and mower decks.
Factory diagrams, specifications, troubleshooting charts and repair procedures are included throughout.
You will receive the complete 468-page TM1574 technical manual on CD-ROM.
Please verify that TM1574 is the correct manual for your tractor before purchasing.
