NEW IN BOX Omega FMA5520A Mass Flow Controller (10 LPM max) with LCD Display For Sale

Brand new and unused. Open to Offers!
BrandAccuracy± 1 %Accuracy DetailFor units with full range less than 100 SLM ± 1% FS, including linearity over 15 to 25°C (59 to 77°F) and 0.7 to 4.2 kg/cm² (10 to 60 psia). For units ≥ 100 SLM Full Range: ± 1.5% FS, including linearity over 15 to 25°C (59 to 77°F) and 0.7 to 4.2 kg/cm² (10 to 60 psia) from 20 to 100% of range; ± 3% FS from 0 to 20% of rangeAltitude SensitivityHorizontal flow path, no shift in calibration up to +20 degree pitchCalibrationNIST CertificateControl ValveSolenoid ValveDisplay TypeLCDElectrical Output4 to 20 mA, 0 to 5 VdcEnclosure RatingsInst. Level II/Poll. Degree II (IEC 60664)GrossWeightValue2.3Humidity Range0 to 70% RHLeak Rate Under Vacuumless than 10^⁻⁷ cc He/sMaterial Construction OptionAluminum and Brass BodyMaterials, Wetted316 Stainless Steel, Anodized Aluminum, Brass, FKMMedia CompatibilityClean dry air / inert gas, HVAC / room air, Inert / non-reactive gases, OxygenOperating Pressure Note35 kg/cm² gage (500 psig); 70 kg/cm2 gage (1000 psig) for ranges up to 100 SLPM. 1.76 kg/cm (25 psig) optimumOperating Pressure, Max1000 psiOperating Pressure, Min0 psiOperating Temperature, Max50 °COperating Temperature, Min5 °COutput DetailLinear 0 to 5 Vdc: 1000 V minimum load 4 to 20 mA: 50 to 500 V loop resistance, ± 20 mV max noiseOutput SignalCurrent, VoltagePressure Coefficient0.01% FS/psiPressure Drop, Max50 psiProcess Connection Size1/4 inProcess Connection TypeCompression FittingRepeatability± 0.5%Response Time5 secResponse Time Note5 seconds to within ± 2% of set flow rate over 25 to 100% FSSeries IDFMA5000A-SeriesSupply CurrentUp to 800 mASupply Voltage12 to 15 VdcTemperature Coefficient0.15% FS/°CTurndown Ratio40:1Volumetric Flow Rate, Max10 SLMVolumetric Flow Rate, Min0.25 SCCM, 0.25 SLMCountry of OriginUnited States
