KOLSOL NF-826 Network Tracking Device Wire Circuit Breaker Cable Tester Phone Cable Detector Locator Meter Tracking Device
Main features
Detecting cables, electrical lines-water/gas supply pipelines buried in wall or earth
Detecting interruptions and short circuit in cables and electrical lines buried in wall or earth
Detecting fuses and assigning current circuits.
Both transmitter and receiver display power level, code, battery, detected voltage type and value, and high-voltage alert.
Transmitter built in DC/AC voltage meter for linear measurement of 12-400V DC/AC voltage
Large LCD screen on transmitter & receiver with digit readout, bar graph and sound to easily determine wire location
Applications:
Installation and maintenance of weak current system, communication line,comprehensive wiring circuit, telephone system, computer network, other metal wire circuit etc.
Specification
Transmitter
LCD Screen
52*35mmTN screen with backlight
transmitter signal frequency
125KHz
Signal Vp-p
<8V
transmitter self-inspection
Yes
Circuit voltage testing
DC:12~400V +/-2.5%
Interface type
multimeter jack
Max working current
< 250 mA
Demension
158*80*33mm
Receiver
LCD Screen
52*35mmTN screen with backlight
Received signal strength display
√
recognize low battary warning of transmitter
√
Received signal frequency
125KHz
Max reception range
<60cm
Short circuit detection
√
open circuit detection
√
Automatic frequency sweep
√
Reception mode
Manual / Auto
NCV function
Auto-off time
10 mins
Max working current
<250 mA
Demension
228*74*28mm
General
Key
silicon keys * 8
Accpetable transmitter signal codes
6 types
Acceptable transmitter signal amplitude
3 degrees
Buzzer
√
Mute
√
Lamp
√
LCD backlight
on/off
Power supply
3.7V 1400mAh Lithium battary
Battary indicator
√
Charging voltage
DC5V
Charging current
<600mA
Package includes:
1pc x Test lead (red/black)
1pc x Crocodile clamps (red/black)
1pc x Test probe (red/black)
2pc x Built-in battary (red/black)
1pc x Grounding rod
1pc x Carry bag
1pc x Color box
1pc x User manual
