Technical SpecsBest Use
Mountain Biking
Frame
6061 aluminum multi-speed frame
Mountain Bike Style
Trail
Bike Suspension
Front Suspension
Fork
SR Suntour XCT JR24
Fork Travel
80 millimeters
Crankset
Alloy, 3-piece, 30T
Bottom Bracket
Cartridge
Shifters
Shimano Tourney Revo 8-speed
Front Derailleur
Shimano Tourney
Rear Derailleur
Shimano Tourney
Rear Cogs
Shimano Tourney, 11/34T, 8-speed
Number of Gears
8 gear(s)
Brake Type
Hydraulic Disc Brake
Brakes
Tektro hydraulic disc
Brake Levers
Tektro
Rims
Alloy, double-wall
Front Hub
Joytech, 36h, QR
Rear Hub
Joytech, 36h, QR
Wheel Size
24 inches
Tires
24 x 2.6 in.
Tire Width
2.6 inches
Handlebar Shape
Riser Bar
Handlebar
Aluminum
Stem
Alloy
Seat Post
Alloy
Saddle
Co-op Cycles
Pedals
Composite platform
Headset
Semi cartridge
Chain
KMC
Weight
31 pounds
Bike Weight
Bike weight is based on median size, as sold, or the average of two median sizes.
Gender
Kids\'
Sustainability
From a Climate Label Certified brand
Size ChartCo-op Cycles Bikes (215700)24 INHeight Range4\'2\" - 4\'10\"Reach336Stack540Effective Top Tube511Seat Tube Center-Top290Standover Height647Head Tube Angle (degrees)69Seat Tube Angle (degrees)72Wheelbase973Chainstay410Fork Offset40Sizing Notes
Measurements are stated in millimeters unless otherwise indicated.
Features
- Designed to fit kids 4\'2\"–4\'10\" (typically ages 8–12) with an inseam length of 24–28 in.; see size chart for detailed buying guidance
- Lightweight 6061 aluminum frame has a suspension fork with 80 mm of travel to soak up bumps for enhanced control
- 8-speed, 1x gearing keeps shifting simple while offering plenty of options for climbing and cruising
- Hydraulic disc brakes provide confidence-inspiring, responsive braking power in all conditions
- Extra-wide, 2.6 in. all-terrain tires soften the little bumps and stick to the trail for a smooth, stable ride
- Bicycle weight limit is 120 lbs. total, including rider + all gear carried on the bike and on the rider\'s body
- NOTE: Specs and images are subject to change based on component availability
