SpecificationsMaterial: Iron, Zinc Alloy, PlasticProcess: Painted and ElectroplatedColor: SilverMounting Type: Door MountAdjustable Range: Vertical and Horizontal ±3mm/0.12in, Tilt +4mm/0.15inPacking Size: Bar Adjustable Range: 50-94cm/19.68-37inSide Bracket Size: 33.5*12cm/13.18*4.72inPneumatic Arm Extendable Length: 6.5cm/2.55inPneumatic Arm Length: 12cm/4.72inGross Weight: 2.5kg/5.51lbsNet Weight: 2.15kg/4.73lbsLoading Capacity: 5kg/11lbsPneumatic Arm: 250N Package Included2* Side Bracket2* Pneumatic Arm2* Pneumatic Support Rods1* Allen KeyAll Accessories Required for Installation
2pcs Cabinet Door Hinges Folding Lift Up Top Vertical Swing Furniture Hardware2pcs Cabinet Door Hinges Folding
Description
This pneumatic arm hinge is made of high-quality iron, zinc alloy and plastic, which is very strong and has good load-bearing performance. It is equipped with a pneumatic arm, you will achieve a quiet, stable, gentle switch cabinet door. This versatile black pneumatic arm hinge will match your cabinets of various styles and colors.
Key Features
Parallel-moving Design:Compared to traditional front and back opening cabinet doors, this kind of up and down parallel moving pneumatic arm hinge does not take up too much space and is more suitable for small spaces. It also protects your head from bumps and bruises, making it safer and more secure.
Silent Opening and Closing:Its excellent pneumatic mechanism and flexible bracket axis allow the door to open and close smoothly and silently, giving you a quiet and comfortable user experience.
Sturdy and Durable: It is made of high-quality iron and zinc alloy, which is sturdy, wear-resistant, and not easily deformed, ensuring a long service life.
Exquisite Surface Process: Its surface is painted and electroplated to give it good resistanceto rust, corrosion, and oxidation. As a result, it is inclusive of the installation environment, which can be installed in kitchens, bathrooms, laundry rooms, etc.
High Load-bearing Capacity:Its robust material and powerful pneumatic arm(250N) provide sturdy construction and a strong load-bearing capacity that can support cabinet doors weighing up to 5kg/11lbs.
Adjustable Design:The installation position of the door can be adjusted using the adjustment screws. The vertical and horizontal adjustment screws change the vertical and horizontal position of the door by ±3mm/0.12in and the tilt adjustment screws tilt the door by +4mm/0.15in to meet your different needs.
Easy to Install: Its simple construction and complete range of mounting accessories facilitate installation. You can install it independently in a short time.
Customer Service:We aim to provide quality products and services. If you have any problems, please feel free to contact us. We will reply and solve the problem for you as soon as possible.
Details
Pneumatic Lever: It is equipped with a pneumatic lever with a cushioning function for gentle opening and closing. It prevents abrupt lifting up and homing, ensuring a stable, smooth, silent, effortless lifting up and return.
Adjustable Connection Bar: The connecting bar keeps the side brackets balanced and avoids wobbling. Its length can be adjusted(19.68-37in) to accommodate a wider range of cabinets.
Application
It is applicable to the cabinet for placing microwave oven, disinfection bowl device, automatic bowl cleaning device, etc. It is suitable for doors weighing less than 11lbs and cabinets with a width of 600-900mm/23.62-35.43in, a height of more than 320mm/11.81in and a depth of more than 220mm/8.66in.
How to Install
1. Aim the left and right of the main body onto the left and right upper positions of the cabinet and tighten the screws.
2. Connect synchronous cudgel. Tighten the two sides with screws.
3. Assemble the fixing stand on the back of the door plank.
4. Fit the door plank onto the two holding arms
5. Adjust after assembling the three functions of the fitting stand, including namely level, vertical, and tilting.
Specifications
Material: Iron, Zinc Alloy, Plastic
Process: Painted and Electroplated
Color: Silver
Mounting Type: Door Mount
Adjustable Range: Vertical and Horizontal ±3mm/0.12in, Tilt +4mm/0.15in
Packing Size: 21.5*14.5*4.5cm/8.46*5.7*1.77in
Connection Bar Adjustable Range: 50-94cm/19.68-37in
Side Bracket Size: 33.5*12cm/13.18*4.72in
Pneumatic Arm Extendable Length: 6.5cm/2.55in
Pneumatic Arm Length: 12cm/4.72in
Gross Weight: 2.5kg/5.51lbs
Net Weight: 2.15kg/4.73lbs
Loading Capacity: 5kg/11lbs
Pneumatic Arm: 250N
Package Included
2* Side Bracket
2* Pneumatic Arm
2* Pneumatic Support Rods
1* Allen Key
All Accessories Required for Installation
Notes
Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before you order.
