6L80 ATSG Rebuild Manual 6L90 6L80E Automatic Transmission Overhaul Service Book:
$45.00
Rebuild manual for the GM 6L80 and 6L90 automatic transmission. Product specifics: - Publisher:ATSG – Automatic Transmission Service Group
- ATSG part number:6L80E
- Book type:Rebuild and overhaul – Techtran manual
- Covered models: 6L50, 6L50E,6L80, 6L80E, 6L80-E, MYC, 6L90, 6L90E, 6L90-E, MYD
- Makes:GM, Cadillac, Chevrolet, GMC, Hummer, and Pontiac
- Year of origin:USA
The blue cover 6L80 ATSG overhaul manual covers procedures and technical service information for transmission inspection, repair, dis-assembly, assembly, diagnosis, and troubleshooting. This book contains detailed information regarding the following: - Bushing locations
- Checkball locations
- Clutch clearance specifications
- Electrical volt and ohms information
- Endplay check and recommendations
- Exploded views
- Line pressure check procedures and specs
- Recommendedtools list – Not all required
- Thrust washer locations
- Torque specifications
- Torrington bearing locations
- Transmission model application codes
- Trouble codes and fixes
- Trouble shooting
- Valve body assembly detail for valves and springs
- Much more…
These transmissions can be found in the following vehicles; however, you should double check your application. It is common for similar vehicles to have multiple transmission options available from the factory. Buick - Electra 2010-2011
- Park Avenue style="box-sizing: border-box;">CTS V6 2008-2015
- CTS 6.0L, 2007-2009
- CTS, CTS-V 6.2L, 2009-2013
- Escalade EXT & ESV, 2007-2015
- SRX Wagon 2007-2009
- STS 2007-2011
- STS-V V8 Supercharged, 2006-2011
- XLR, 1500, 2009-2012
- Camaro, 2009-2016
- Caprice, 2009-2013
- Colorado 2015-2022
- Colorado 5.3L, 2008-2012
- Corvette, 2007-2014
- Express Van 2500 & 3500, 2009-2017
- Silverado Truck 1500 & 2500, 2008-2017
- Silverado Truck 2500HD, 3500HD 6.0L 2008-2017
- Suburban 1500 & 2500, 2009-2017
- Tahoe, 2009-2017
GMC - Canyon 2015-2022
- Canyon 5.3L, 2008-2012
- Savana Van 2500 & 3500, 2009-2017
- Sierra Truck 1500, 2500, 2008-2017
- Sierra Truck 2500HD, 3500HD 6.0L, 2008-2017
- Yukon, 2009-2017
- Yukon XL 1500, 2009-2017
- Yukon Denali, 2008-2010
- H3 5.3L, V8 2008-2010
These transmissions are part of the Turbo Hydramatic or Hydra-Matic series and known by the following codes and part numbers: 6L50, 6L50E, MYB, 6L80, 6L80E, 6L80-E, MYC, 6L90, 6L90E, 6L90-E, MYD. This transmission rebuild guide covers the following years: 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, and 2022
|
