Dental Scatter Shield Protective Ring Fit For RAY-121/221 Unit Machine Rayos For Sale

Machine RAY-121

Features:
1.This portable dental X-ray unit is high frequency machine.
2.The body is small, light weight and nearly no radiation.
3.It has excellent image quality, portable storage, save more space.
4.It uses high frequency and DC international power supply.
5.All of the components installed in the central PC board concentrated. Shock,set-up, electron tubes, all of them are insulation vacuum, sealed stereotype protection.
6.There are also manual buttons installed on the surface of shell, as well as batteries and charges7.This unit mainly suitable for oral pre-treatment for learning internal organizational structure, root depth and so on, is indispensable in daily life clinic equipment, especially for dental implant surgery.
8.It also can connect with sensor, is great convenience.
9.The battery is durable, it can take about 5 hundred images after fully charged.
10.It can be connected with intra-oral digital X-ray imaging system.

Warning: After turning on the machine, wait for 1 minute, the voltage can be stabilized before normal use；After each photo taking, you need to wait for the normal value to return before taking a normal photo.

Technical Parameter:
Tube voltage：60KV

Tube current：2mA

Exposure time：0.1~2.0s

Frequency：30KHz
Rate power：120VA

Distance from skin to cone：118mm
Tube focus：0.4mm×0.4mm

Battery：DC14.8V 2200mAh

Charger input voltage：AC100V-240V±10%

Output voltage: DC16.8V
Ambient temperature: 5℃~40℃
Relative temperature: <75%RH

Packing List:
Main body 1pc
Charger 1pc
User manual 1pc

• Machine RV-210RH(with Shield)

• Features:
  5-inch touch screen, intuitive and user-friendly operation
  Low radiation leakage, four-layer shielding with lead glass for maximum safety

  Lightweight design, compact and portable for flexible clinical use
  Adjustable kV/mA and 0.01–2.0s exposure time, meeting diverse clinical needs
  Solid insulation with efficient cooling, no oil leakage, stable for continuous shooting

  Bluetooth controller and tripod support, offering options for remote control and steady imaging

  Technical Parameter:
  Voltage: DC 22.2V

  Battery: 950mAh / 21.09Wh

  Focus-to-skin distance: ≥200mm

  Tube voltage: Adjustable 60kV / 65kV / 70kV

  Tube current: Adjustable 2mA–3mA

  Exposure time: 0.01–2.0s

  Net weight: 1.6kg

  Charging input: AC 100–240V

  Charging output: DC 25.2V

  Inverter frequency: 70kHz

  Packing List:
  Portable Dental X-RAY Machine 1pcs

  Charger 1 pcs

  Remote controller 1pcs

  Back-scatter shield 1pcs

Feature:

• If there’s only one device, you may select “Single-User” installation. If the sensor is connected to multiple device, select “Host” for the device connected with the sensor and other devices select “Extension” to install, to achieve multi-machine sharing.
• The sensor is available in two sizes, with rounded corners and a thickness of only 4.4mm, making it more comfortable to use.
• Cables are durable，have been tested for 80,000+ bends.
• CMOS detector technology with CSI scintillator. Ensures optimal resolution Low dose clinical imaging.
• Compatible with different X-ray generators, easy to use.
• No consumables and more cost-effective than traditional film.

Hardware and software requirement：

Processor ：1.0GHz or above

Memory ：2GB or above

Hard disk ：64GB or above

Display resolution ：1440*900 or above

USB port ：USB2.0

Operating system ：Windows 7、Windows10、Windows11

Technical parameter：

S1

S1.5

S2

Detector Technology

APS CMOS

APS CMOS

APS CMOS

Scintillator

CsI

CsI

CsI

Theoretical Resolution

25lp/mm

25lp/mm

25lp/mm

True Resolution

20lp/mm

20lp/mm

20lp/mm

Pixel Matrix

1000*1500

1300*1800

1300*1800

Active Area(mm)

20*30

26*36

26*36

Mechanical Size(mm)

25.4*38.2*4.5

30.4*44*4.5

Data interface

USB 2.0

USB 2.0

USB 2.0

AD Conversion(bit)

16

16

16

Protection

IP68

IP68

IP68

Packing list：

1. Sensor

2. USB flash disk (Software)

3. Protective sleeve

4.X-ray position system

Dental x-ray machine with display screen/Dental x-ray machine.

AZdentPortable dental X-ray machine,versatile dental X-ray machine with built-in display for instant image viewing.

FEATURE：

• Instant Image Display:When connected to our sensors, built-in screen shows X-ray images immediately after capture.
• Independent Operation: Functions seamlessly even without the sensor connected.Compatible with digital sensors, X-ray film, and image plate scanners.
• Flexible Sensor Use:Sensor can be paired with other X-ray machines, allowing versatile integration across different setups.
• Enhanced Workflow:Streamlined design improves efficiency and adapts to various clinical needs.
• Effortless Image Transfer:Easily transfer captured images to a computer via USB or Bluetooth.
• Sensor Options: You can choose one of the two sensor models to suit different needs.
• Handheld Design:Easy-to-grip, portable X-ray machine for convenient use and mobility.
• The body is small, light in weight, and the radiation leakage is less than 20μgy/h.
• It has excellent image quality, portable storage, save more space.
• It uses high frequency and DC international power supply.
• All of the components installed in the central PC board concentrated. Shock,set-up, electron tubes, all of them are insulation vacuum, sealed stereotype protection.
• Different exposure times are preset for adults and children.
• The battery is durable, it can take about 4 hundred images after fully charged.

TECHNICAL SPECIFICATIONS：

• Tube voltage：60KV
• Tube current：2mA
• Exposure time：0.1-2.0S
• Frequency：30kHz
• Rate power：120VA
• Distance from skin to cone：105mm
• Tube focus：0.8mmx0.8mm
• Battery：DC14.8V 1600mAh
• Charger input voltage：AC100V-240V+10%
• Output voltage：DC16.8V
• Ambient temperature：5℃~40℃
• Relative temperature：<75%RH

Sensor technical parameter：

Model

COX2230

COX2635

Detector Technology

APS CMOS

APS CMOS

Pixel Size

18.5μm

Theoretical Resolution

27lp/mm

True Resolution

CsI：≥14 lp/mm

Pixel Matrix

1200*1600

1402*1888

Active Area(mm)

29.6´ 22.2

35´ 26

Mechanical Size(mm)

39´ 28.5´ 6

44.5´ 33.0´ 6

Data interface

USB

Digitization

12/14/16 bit

Imaging Time

3-4s

Package：

• Aluminum box *1
• X-ray machine *1
• Sensor (with U disk) *1
• Charger *1
• Manual*1
• Data cable*2
