The Milbank U9320-RXL is a 125-amp, 7-terminal ring-type overhead/underground meter socket housed in a NEMA Type 3R rated steel enclosure. Designed for single-phase residential and light commercial metering applications, this unit features a lever bypass (LVR) mechanism for continuous power during meter removal. The unit appears new and unused, removed from its original box.
Features & NumberU9320-RXLProduct TypeRing-Type Meter Socket with BypassAmperage Rating125A ContinuousVoltage Rating600V ACNumber of Terminals7 (Line & Load)Wire Range6 AWG - 2/0 CU/ALBypass TypeLever Bypass (LVR)Enclosure TypeNEMA Type 3R (Outdoor Rated)Series757Short Circuit Rating10,000 RMS SYM Amps, 600 VACTerminal TorqueLine/Load: 6 AWG #6 Terminal; Hex 150 LB-IN Max; Slotted 50 LB-IN MaxPhasesSingle PhaseColorGrayCountry of OriginUSAMfg Date05-25-16What's Included
- 1x Milbank U9320-RXL Meter Socket
- Meter Socket Cover/Door
- Closure pad (original pad in place)
- Original box with standard single-phase utility meters for residential and light commercial installations. Fits standard ring-type meter bases accepting 7-terminal wiring configurations. Consult local utility requirements before installation. Conduit hubs sold separately (see Milbank accessory catalog for hub and closing plate part numbers).
