Up for sale is a brand new, unused Parker Skinner 5-Port 4-Way Solenoid Valve (Part Number: 73417AKDKNM0G0J222P3). This high-quality industrial pneumatic valve belongs to the rugged 7000 Series (VAP line) and is designed for reliable double-acting cylinder control or automation valve actuation.
Because it features an aluminum body, it provides heavy-duty performance while remaining lightweight. The unit is in flawless, brand-new condition and ready for immediate deployment.Technical Specifications
• Manufacturer: Parker Hannifin / Skinner
• Series / Family: 7000 Series VAP Product Line
• Part Number: 73417AKDKNM0G0J222P3
• Valve Type: 5-Port, 4-Way, 2-Position, Internal Pilot-Assisted
• Body Material: Aluminum
• Seal Material: NBR (Buna-N / Nitrile)
• Flow Rating: 11/64" Orifice / Approx. 0.55 Cv Flow Factor
• Manual Override: Equipped with a locking manual override slot (M0 suffix code)
Connection & Port Configurations
• Process Ports (End A & End B): 1/4" Female NPT (Includes 1 pressure inlet port, 2 cylinder delivery ports, and 2 exhaust ports)
• Electrical Connection: 1/2" NPT Conduit Housing with flying wire leads for secure, hardwired electrical installation
Electrical & Operating Parameters
• Coil Voltage: 110V/50Hz - 120V/60Hz AC
• Compatible Media: Air or inert gases
• Operating Pressure (MOPD): 30 PSI minimum (required to actuate internal pilot) up to 150 PSI maximum
• Max Ambient Temperature: 167°F (75°C)
