1071399TIM361-2134101Compact 2D LiDAR sensor - class 1 Infrared (IR) laser beam - for indoor and outdoor applications - SICK (TiM series) - TIM361-2134101 - 50mm...10m working range - 0.33° horizontal angular resolution - 270° aperture angle (horizontal) - Pre-equipped with 4-pin M12 female connector (Ethernet) + Pre-equipped with 12-pin M12 male connector (pwr.) + Pre-equipped with Micro USB female connector (type B) - 3 x digital outputs (PNP; additional 1 x \"Device Ready\") - 4 x digital inputs - 9Vdc-28Vdc (12Vdc / 24Vdc nom.) supply voltage - IP67 - Gray (RAL 7032) color - with Ethernet communication capability - Rated for -13°F...+122°F / -25°C...+50°C ambientSpecificationsPrimary brandSICKMain functionSensor (2D LiDAR)Product series / family nameDetection sensors > LiDAR and radar sensors > 2D LiDAR sensors > CompactSub-range nameTiM seriesFunctionsCompact 2D LiDAR sensorDesignclass 1 Infrared (IR) laser beam
for indoor and outdoor applications
parameterization
service interface
for detecting (perforated object / level) / measuring (dimension / contour and volume / level) / protecting objects (vehicles) / determing 2D positionSupply voltage (DC)9Vdc-28Vdc (12Vdc / 24Vdc nom.)Sensing distance50mm...10m working rangeField of view270° aperture angle (horizontal)Frequency15Hz scanning frequencyDisplay2 x LED indicators (ON; switching status)Wavelength850 nmColorGray (RAL 7032)Connection typePre-equipped with 4-pin M12 female connector (Ethernet)
Pre-equipped with 12-pin M12 male connector (pwr.)
Pre-equipped with Micro USB female connector (type B)Communication protocolEthernetDigital inputs4 x digital inputsDigital outputs3 x digital outputs (PNP; additional 1 x \"Device Ready\")Response time67ms-134ms / 0.067s-0.134 sResolution0.33° horizontal angular resolutionDegree of protectionIP67DimensionsH86mm x W60mm x D60mmAmbient air temperature for operation-13°F...+122°F / -25°C...+50 °CAmbient air temperature for storage-40°F...+167°F / -40°C...+75 °CPower consumption(typ.) 4 W
(max) 16 WETIM code(ETIM 5.0) EC002550
(ETIM 6.0) EC002550eClass code(EClass 5.0) 27270990
(EClass 5.1.4) 27270990
(EClass 6.0) 27270913
(EClass 6.2) 27270913
(EClass 7.0) 27270913
(EClass 8.0) 27270913
(EClass 8.1) 27270913
(EClass 9.0) 27270913Order code / Manufacturer SKU1071399
TIM361-2134101Manufacturer product statusCommercializedUNSPSC code(UNSPSC 16.0901) 41111615Compliant with standard(s)EN 61000-6-3 (residential area)
EN 61000-6-2 (industrial environment)
European Conformity (CE)
UKCA
cTUVus
Sine test - 5g; 10Hz to 500Hz; 10 frequency cycles
Sine resonance scan - 10Hz to 1000Hz
Noise test - 4.24g RMS; 10Hz to 250Hz; 5hrs
Shock resistance - 50g; 1ms; 3 single shocks/axis
Shock resistance - 25g; 6ms; 1000 continuous shocks/axis
Shock resistance - 50g; 3ms; 5000 continuous shocks/axisClassProtection class IIIBenefitsProduct description
The TiM3xx 2D LiDAR sensor uses HDDM technology‚ which minimizes machine downtimes thanks to high measurement accuracy and ambient light immunity.
Its monitoring field can reach up to 10m.
Commissioning is quick and easy thanks to 16 preconfigured field sets (each with 3 fields)‚ which are selected via the input circuit.
The TiM3xx is flexible‚ cost-effective‚ and user-friendly.
It is particularly suitable for mobile and stationary applications in factory automation and logistics automation.
A version certified for safety-related applications according to EN ISO 13849- 1ː2015 is also available (TiM3xxS).
Low power consumption and a compact and rugged design makes the TiM3xx ideal for use on mobile platforms.
At a glance
- Incredibly compact‚ light‚ and economical sensor
- Field evaluation using intelligent software algorithms
- Configuration interface accessible from the side when the device is mounted
- Low power consumption (typically 4 W)
- TiM3xxS onlyː Certified to Machinery Directive 2006/42/EG and DIN EN ISO 13849-1ː2015
Your benefits
- Low operating costs
- Flexible installation due to compact dimensions
- Low implementation and replacement costs due to M12x12 or D-Sub male connector
- Long battery service life when used in battery-operated vehicles
- Easy commissioning thanks to preconfigured field sets
- Low costs as a result of monitoring large fields (up to 235m2) with just one scanner
- No cabling required between sender and receiver
- For TiM3xxS onlyː Can be used in safety-related applications
