Supermicro MBD-X11DPI-NT Dual LGA3647/ Intel C622/ DDR4/ SATA3&USB3.0/ EATX MB
620.0 USD
Free SKUsMBD-X14SBI-FPhysical Stats- Form Factor: ATX
- Dimension: 12.3" x 10.5" (31.24cm x 26.67cm)Processor- CPU: Single Socket E2 (LGA-4710)
- Supported Processors: Intel® Xeon® 6700/6500 series processors with P-cores or 6700 series processors with E-cores
*BIOS 1.2 or above required for P-core models
- Specific CPUs: Intel® Xeon® 6781P, 6761P, 6741P, 6731P, 6521P, 6511P
- Core Count: Up to 144C
- Note: Supports up to 350W TDP CPUsSystem Memory- Memory: 8 DIMM Slots
- Max Memory (1DPC): Up to 512GB ECC DDR5 RDIMM
- DIMM Sizes: MRDIMM (P-core only): 32GB, 64GB; RDIMM: 16GB, 24GB, 32GB, 48GB, 64GB, 96GB, 128GB; 3DS RDIMM: 256GB
- Memory Voltage: 1.1V
- Error Detection: Corrects single-bit errors; Detects double-bit errors (using ECC memory)On-Board Devices- Chipset: System on Chip
- SATA: 4 SATA (6Gbps) via ASMedia ASM1164; via SlimSAS
- IPMI: ASPEED AST2600 BMC
- Network Controller: Dual LAN with 1GbE with Intel® I210Input / Output- LAN: 2 RJ45 1 GbE LAN ports; 1 RJ45 1 GbE Dedicated IPMI LAN port
- USB: 2 USB 3.2 Gen1 ports (Header); 2 USB 3.2 Gen1 ports (Rear)
- Video: 1 VGA D-Sub Connector port
- Serial: 1 COM port (header)
- TPM: 1 TPM headerExpansion Slots- PCI-Express (PCIe) Configuration: 3 PCIe 5.0 x8 slots; 3 PCIe 5.0 x16 slots; 6 PCIe 5.0 x8 via MCIO Connector slots
(PCIe5.0 Slot 6 and JNVME3-6 are enabled with the specific CPU**installed)
- M.2: 2 M.2 PCIe 5.0 x2 slots (M-key 22110)System BIOS- BIOS Type: AMI 64MB UEFI
- BIOS Features: ACPI 6.5; SMBIOS 3.7 or later; UEFI 2.9Management- Software: SuperCloud Composer®; Supermicro Server Manager (SSM); Super Diagnostics Offline (SDO); Supermicro Thin-Agent Service (TAS); SuperServer Automation Assistant (SAA) (New!); Plug-ins for 3rd Party SoftwareSecurity- Hardware: Trusted Platform Module (TPM) 2.0PC Health Monitoring- Voltage: +12V, +3.3V, +5V, +5V standby, 7-fan status, Chassis intrusion header, Memory Voltages, Monitors CPU voltages, Supports system management utility, System level control, VBAT
- LED: CPU/system overheat LED; UID/remote UID LED
- Temperature: CPU thermal trip support; Monitoring for CPU and chassis environment; PECI; Thermal monitor 2 (TM2) support
- FAN: 7x 4-pin fan headers (up to 7 fans); Fan speed control; Overheat LED indicationOther Features- ACPI power management; Chassis intrusion detection; Control of power-on for recovery from AC power loss; M.2 NGFF connector; UID; WOLOperating Environment- Environmental Spec.:
Operating Temperature: 0°C to 50°C (32°F to 122°F)
Non-operating Temperature: -30°C to 60°C (-22°F to 140°F)
Operating Relative Humidity: 8% to 80% (non-condensing)
Non-operating Relative Humidity: 8% to 90% (non-condensing)
