Features:
1. Luogang Steel Forgings
2. High temperature quenching treatment
3. Pull/press dual purpose
4. Wide range of applications
5. Carrying case
Specification:
Specification:
Valve port inner diameter: 24mm-53mm
53mm, 50mm, 47mm, 44mm, 42mm, 40mm, 38mm, 36mm, 34mm, 32mm, 30mm, 28mm, 26mm, 24mm
Material: Luofan Steel
Weight: 6KG
How to use the puller:
When using, measure the inner diameter of the valve seat first, and then select the broach (the broach is engraved with the inner diameter of the valve seat), generally according to the inner diameter of the valve seat, the approximate broach size can also be used, but the valve The inner diameter of the seat ring is larger than the broach and put it on the slider, then put it on the valve seat ring, adjust the blade of the broach on the rod, and aim at the bottom of the valve seat ring. For a quarter or one-eighth of the Luo Mao, continue to tighten the Luo Mao. Repeat this several times to gently pull out the valve seat.
How to use the compressor:
When in use, first select the size of the gasket to match or match the size of the valve seat ring, insert the valve seat ring on the cylinder head, and insert the size about 1mm or 2mm, and then select the positioning guide rod (8, 9 , 12) Align the gasket sleeve on the valve seat ring, insert the positioning guide rod into the valve guide tube, tighten the lower flange, and rotate the upper flange to press the valve seat ring into the cylinder head smoothly.
