This fan features a permanent split-capacitor AC motor with dual ball bearings for reliable, maintenance-free operation in demanding industrial environments.
Specifications
- Manufacturer: Comair Rotron
- Series: Muffin XL AC
- Model: MX2B1
- Part Number: 028420
- Product Type: AC Axial Cooling Fan
- Rated Voltage: 115 VAC
- Operating Voltage: 99–121 VAC
- Frequency: 50/60 Hz
- Rated Current:
- 0.22 A @ 60 Hz
- 0.28 A @ 50 Hz
- Power Consumption:
- Nominal Speed:
- 3100 RPM @ 60 Hz
- 2700 RPM @ 50 Hz
- Maximum Airflow:
- 100 CFM @ 60 Hz
- 84 CFM @ 50 Hz
- Maximum Static Pressure:
- 0.34 in. H₂O @ 60 Hz
- 0.28 in. H₂O @ 50 Hz
- Noise Level:
- 51 dBA @ 60 Hz
- 49 dBA @ 50 Hz
- Dimensions:
- 120 x 120 x 38 mm
- 4.72\" x 4.72\" x 1.50\"
- Bearing Type: Ball Bearings
- Frame Material: Die-cast Magnesium Alloy
- Blade Material: Magnesium Alloy
- Termination: 0.120\" Quick-Connect Terminals
- Operating Temperature: -10°C to +70°C
- Mounting: Standard 120 mm Four-Hole Panel Mount
- Protection: Impedance Protected
- Approvals: UL, cUL, CE (varies by revision)
Features
- Genuine Comair Rotron OEM fan
- High-airflow Muffin XL series
- Continuous-duty industrial design
- Long-life dual ball bearings
- Rugged die-cast magnesium frame
- Low-maintenance AC motor
- Excellent cooling performance for industrial electronics
- Standard 120 mm mounting pattern
Typical Applications
- CNC machine tools
- PLC control cabinets
- Electrical enclosures
- Servo drives
- Variable frequency drives (VFDs)
- Power supplies
- Telecommunications equipment
- Laboratory instrumentation
- Industrial automation systems
- OEM machinery
