Store Categories Store Categories DC Surge Arrestor for PV GSPV8 Series
Product Description
This DC surge protective device is applied low voltage standard IEC EN 61643-11 to protect against DC power line
system and other equipment from over voltage and instantaneous over voltage damage. Widely used in photovoltaic
comber box, power inverter, DC distribution cabinet etc. It has advantages of large discharge current, fast respond
time, low residual voltage. Max. PV voltage up to UCPV ≤1000V dc.
Main features
1. High discharge capacity, quick response, module pluggable;
2. Fast response time, din rail installation;
3. Double thermal disconnection devices, provide more reliable protection;
4. Green window means normal, red means defect, need to change module;
5. Remote alarm terminal optional.
6. T1+T2 surge protection.
Technical parameter
Model GSP9-C40PV Test standard IEC/EN 61643-11;GB18802.11 IEC test classification T1+T2/Class I+ II Max. PV voltage [ Uc pv ] 600/1000/1500V Nominal discharge current (8/20µs) 20kA Maximum discharge current(8/20µs) 40kA Iimp current (10/350µs) 6.25kA Poles 2P,3P Voltage protection level Up pv 2.6kV,3.6kV Response time Ta 25ns Connecting cable 4mm2(L-N); 6mm2(PE) Method of Installation 35mm Din Rail Matched fuse or circuit breaker 32A Type of remote signaling contact Switching contact(Optional) C+NC: Normally closed C+NO: Normally open C: Common contact Switching capacity AC:250V/0.5A DC:250V/0.1A,125V/0.2A,75V/0.5A Cross-sectional area for remote signal
contact Max. 1.5mm2 solid / flexible Operating temperature range 40°C...+80°C
Packing
Packaging containing: SPD *1 PCS & Rail 10mm *1 PCS
More SPD for you consider
AC Type Model kA Pole Voltage Link GSP9-DP40 1P+N 20-40kA 1P+N 275V https://www..com/itm/115939485134 GSP9-DP40 3P+N 20-40kA 3P+N 275V https://www..com/itm/115939523293 GSP9-C40 1P 20-40kA 1P 275/385/400/440V https://www..com/itm/115939546216 GSP9-C40 2P 20-40kA 2P 275/385/400/440V https://www..com/itm/115940316514 GSP9-C40 3P 20-40kA 3P 275/385/400/440V https://www..com/itm/115940337437 GSP9-C40 4P 20-40kA 4P 275/385/400/440V https://www..com/itm/115940337437 GSP9-12.5 1P+N/2P 12.5kA 50kA 1P+N/2P 275V https://www..com/itm/115940388950 GSP9-12.5 3P+N/4P 12.5kA 50kA 3P+N/4P 275V https://www..com/itm/115940393787 DC Type Model kA Pole Voltage Link GSP9-C40PV 2P 20-40kA 2P 600/1000VDC https://www..com/itm/115587883322 GSP9-C40PV 3P 20-40kA 3P 1000/1500VDC
Enclosure (IP 65) Link 5/8/12/WAY https://www..com/itm/395031778179
